Front Seat Backrest Cover - Vehicles Without: Multi-Contour Seats

Removal

1. Refer to: Front Seat (501-10A Front Seats, Removal and Installation).


1. Refer to: Front Head Restraint Guide Sleeve (501-10A Front Seats, Removal and Installation).


1. Refer to: Side Airbag (501-20B Supplemental Restraint System, Removal and Installation).


Vehicles with cloth seats

1. NOTICE: Use care when separating the seat cushion trim cover from the hook-and-arrow or the hook may be torn from the seat cushion foam pad.

   NOTICE: Use care when separating the seat cushion trim cover from the hook-and-loop strips or the hook-and-loop strips may be torn from the seat cushion foam pad.

Vehicles with leather seats

1. NOTICE: Use care when separating the seat cushion trim cover from the hook-and-arrow or the hook may be torn from the seat cushion foam pad.

Installation

1. To install, reverse the removal procedure.
