Parcel Shelf

Removal

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. On both sides.
   Refer to: C-Pillar Upper Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).


1. On both sides.
   Refer to: C-Pillar Lower Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).


1. NOTE: RH side shown, LH side similar.

   On both sides.
   Torque : 9 Nm

1. If equipped.


Installation

1. To install, reverse the removal procedure.
