501-02 Front End Body Panels 2013 - 2014 MKZ
Removal and Installation Procedure revision date: 07/17/2013

Active Grille Shutter

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).
  1. Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).
  1. On both sides.
  1. Torque : 6 Nm

Installation

  1. To install, reverse the removal procedure.
